Horizontal Pulse Vacuum Sterilizer LMPVS-A106

Horizontal Pulse Vacuum Sterilizer LMPVS-A106

Name: Horizontal Pulse Vacuum Sterilizer LMPVS-A106
Brand: Labmate
SKU: LMPVS-A106
Rating: 4.9 (451 reviews)

Horizontal Pulse Vacuum Sterilizer LMPVS-A106 provides capacity of 0.36 m³. It offers range of sterilization modes with adjustable settings, controlled by automated microcomputer system. Its electrolytic polishing meets food-grade standards and ensures multi-channel steam heating with external steam. Its stainless-steel construction, reinforced by advanced welding techniques ensures durability. Our Horizontal Pulse Vacuum Sterilizer is ideal for sterilizing food processing equipment, media, glassware, fabrics.

Catalog Send Mail Whatsapp

Specifications

Volume	0.36 m³
Design Temperature	144°C
Sterilization Temperature Range	105°C to 139°C
Inner Cavity Design Pressure	-0.1 to 0.3 MPa
Inner Cavity Working Pressure	-0.1 / 0.25 MPa
Jacket Design Pressure	0.3 MPa
Jacket Working Pressure	0.25 MPa
Inner Cavity Water Pressure Test	0.39 MPa
Jacket Water Pressure Test	0.52 MPa
Temperature Uniformity	±1°C
Limiting Vacuum	-94.3 kPa
Leakage Rate	Less than or equal to 1.3 kPa / 10 min
Temperature Difference	15°C
Power Consumption	1.2 kW
Power Supply	380V, 50Hz
Chamber Dimension	1000×600×600 mm
Housing Dimensions	1260×1270×1740 mm
Weight	800 kg

Pricing

Product	Price	Unit	Action
Horizontal Pulse Vacuum Sterilizer LMPVS-A106	$ 40675	Each of 1

Features

Single door design

Colour touch screen

Multi-stage heating

Vacuum detection function

Four-sided V-shaped cavity base

Built-in safety mechanisms

Applications

Horizontal Pulse Vacuum Sterilizer LMPVS-A106 is best suited for sterilizing food processing equipment, containers, media, glassware, scientific instruments, surgical tools, fabrics, and other medical supplies in food industry, healthcare and laboratories.
