Microplate Reader LMMR-M102 provides 12 tests per plate for efficient testing. Equipped with Tungsten Halogen Lamp for consistent illumination. It features four standard filters like 405, 450, 492, 630 nm for flexible wavelength selection. Incorporated with 7-inch touch screen for easy navigation. It offers multiple reading export formats, including CSV, XLS, and PDF for easy integration with existing workflows. Our Microplate Reader supports seamless data handling through VGA, USB, audio, and RS-232 ports.
Catalog Send Mail WhatsappSpecifications
| Plate Type | 96 well/48 well |
| Wavelength Range | 400 to 800nm |
| Indication Range | 0.000 to 4.000 OD |
| Test Capacity | 12 tests per plate |
| Resolution | 0.001A |
| Accuracy | ±0.008A |
| Reproducibility | Less than or equal to 0.2% |
| Photodetector | Silicon Photodiode |
| Light Source | Controlled tungsten halogen lamp |
| Optical System | 8-channel fiber scanning, auto plate centering |
| Standard Filters | 405,450,492,630 nm |
| Shaking | Linear, 3 speed settings |
| Display | 7 inch Touch Screen |
| Interface Connections | DVI, VGA, Network Interface, USB, Audio Interface, RS-232 |
| Power Supply | 100~240V, 50~60Hz |
| Dimensions | 460×350× 197mm |
| Weight | 10kg |
Features
Silicon Photodiode Photodetector
8-Channel Fiber Scanning
Linear Motion With 3 Speed Settings
Efficient Power Consumption
Compact Construction
Applications
Microplate Reader LMMR-M102 is vital for quantifying nucleic acids and proteins within molecular biology processes.
Similar Products
Frequently Asked Questions
1 What is a Microplate Reader?
A Microplate Reader is an apparatus designed to detect biological, chemical, or physical events within the wells of a microplate.
2 How does Microplate Reader work?
It works by using optical detection methods such as absorbance, fluorescence, or luminescence to measure reactions in each well of a microplate.
3 Why is Microplate Reader important in drug discovery?
It is important in drug discovery because it enables high-throughput screening, allowing researchers to analyze thousands of samples quickly and accurately.
4 Can Microplate Reader be used for kinetic assays?
It is used for kinetic assays, allowing researchers to monitor changes in absorbance or fluorescence over time.
5 How is Microplate Reader used in ELISA assays?
It is used in ELISA assays to measure absorbance in microplate wells, quantifying the presence of specific proteins or antigens based on colorimetric changes.
6 Can Microplate Reader be used for cytotoxicity assays?
It can be used for cytotoxicity assays by detecting changes in absorbance or fluorescence that reflect cell viability or membrane integrity.
7 Can Microplate Reader be used for bacterial growth studies?
It can be used for bacterial growth studies by continuously measuring optical density, allowing researchers to monitor growth curves over time.
8 Can Microplate Reader be used for hormone detection?
It is commonly used for hormone detection in ELISA- or luminescence-based immunoassays, enabling accurate quantification of hormone levels in biological samples.
9 Can Microplate Reader be used in food safety testing?
It is used in food safety testing to detect contaminants, toxins, or pathogens via immunoassays or enzymatic reactions in microplate formats.
10 How is Microplate Reader used in environmental monitoring?
It is used in environmental monitoring for detecting pollutants, heavy metals, or microbial content using biochemical assays in water and soil samples.
