Dead Weight Tester LMDWT-C101 is streamlined instrument engineered to provide consistent vacuum pressure. Built for long-term performance under both steady and changing load environments. Fitted with premium-grade piston system offering exceptional dimensional stability and minimal performance drift. Constructed in compact and lightweight configuration allowing for easy handling and deployment across various technical settings. Our Dead Weight Tester LMDWT-C101 is ideal for sectors requiring traceable pressure standards and verified accuracy.
Specifications
| Pressure Range | 0.5 to 25 MPa |
| Lower Limit | 0.04 MPa |
| Nominal Piston Area | 0.2 cm² |
| Thread Size | M20 × 1.5 |
| Generated Pressure | 0.04 MPa; 0.1 MPa |
| Accuracy | 0.02% |
| Output Signal | 4–20 mA (AL) |
| Material | Stainless Steel |
| Piston Material | Tungsten Carbide |
| Medium | Isooctyl Sebacate |
| Piston Stroke | ±1.5 mm with Displacement Sensor |
| Operating Temperature | 20 ± 5°C |
| Gross Dimensions | 625 × 500 × 390 mm |
| Net Weight | 27 kg |
| Gross Weight | 35 kg |
Pricing
| Product | Price | Unit | Action |
|---|---|---|---|
| Dead Weight Tester LMDWT-C101 | $ 3906.25 | Each of 1 |
Features
Manufactured using robust tungsten carbide
Withstands temperature variations effectively
Built-in sensor enables piston displacement monitoring
Advanced mechanism ensures consistent pressure generation
Applications
Dead Weight Tester LMDWT-C100 serves as a benchmark calibration system for vacuum pressure validation, widely used in aerospace labs, mechanical calibration setups, and pressure control testing facilities. It serves as the ideal choice for institutions seeking operational reliability, user-focused design, and strict compliance with national metrology standards.
