Single Beam UV/Visible Spectrophotometer LMUS-A311

Single Beam UV/Visible Spectrophotometer LMUS-A311

point.png Wavelength range: 190 nm – 1100 nm

point.png Spectral bandwidth: 0.5 nm, 1 nm, 2 nm, 4 nm, 5 nm

point.png Automatic wavelength setting

point.png Replaceable Pre-aligned lamps (Tungsten and Deuterium)

point.png PC scanning software with USB port

HSCode:9027300000

Get Quote
Wavelength 190 nm – 1100 nm
Spectral Bandwidth 0.5 / 1 / 2 / 4 / 5 nm
Optical System Single Beam, Grating 1200 lines/mm
Wavelength Accuracy 0.3 nm
Wavelength Repeatability 0.1 nm
Wavelength Setting Automatic
Photometric Range 0 – 200 % T, - 0.3 A ~ 3 A
Photometric Setting ± 0.3 % T
Photometric Repeatability 0.1 % T (0 ~ 100 % T)
Detector Silicon Photodiode
Light Source Tungsten Lamp and Deuterium Lamp
Stray Light 0.05 % T (220/360 nm)
Stability ± 0.001 A/h; 500 nm
Data Output Port USB port & Parallel port ( Printer)
Noise ± 0.001 A
Baseline Flatness ± 0.002 A
Display Graphic LCD (320 x 240 Dots)
Power Supply AC 220 / 110 V; 50 / 60 Hz
Dimension 590 x 475 x 250 mm
Net Weight 20 Kg
Gross Weight 26 Kg

point.png Wavelength range: 190 nm – 1100 nm

point.png Spectral bandwidth: 0.5 nm, 1 nm, 2 nm, 4 nm, 5 nm

point.png Automatic wavelength setting

point.png Replaceable Pre-aligned lamps (Tungsten and Deuterium)

point.png PC scanning software with USB port

point.png Low noise and low stray light

point.png Auto 8-cell holder (Optional)

Get Quote for
Single Beam UV/Visible Spectrophotometer LMUS-A311
