Metallurgical Microscope LMMM-705 is designed with infinity plan semi apochromatic objectives 5X, 10X, 20X, and 50X. It offers a trinocular head with 30° inclination for observation and camera connectivity. It features an adjustable interpupillary distance from 48mm to 76mm for strain-free viewing comfort. Built with a durable mechanical stage ensuring smooth slide movement and stable performance. Our Metallurgical Microscope incorporates a polarizing component for optical studies and contrast enhancement.
Specifications
| Magnification Range | 50X to 1000X |
| Eyepiece | WF10X/22mm |
| Reticule Eyepiece | WF10X/22mm |
| Objectives (Semi Apochromatic) | 5X/10X/20X/50X |
| Viewing Head | Trinocular Head |
| Head Position | 30° inclined, 360° rotatable |
| Interpupillary Distance | 48 to 76mm |
| Light Distribution Ratio | 80:20 |
| Polarizing Unit | Polarizer/ Analyzer |
| Nosepiece | Quintuple |
| Focusing Knob | Coaxial coarse and fine focusing knob |
| Coarse Stroke | 25mm |
| Fine Stroke Per Rotation | 0.2mm |
| Fine Division | 2 μm |
| Reflecting Illumination System | 5W LED |
| Mechanical Stage Dimension | 200 ×150 mm |
| Mechanical Stage Adjustment Range | 77 × 52 mm |
| Mechanical Extra Vertical Adjustment | 50mm |
| Power Supply | 100V to 240V |
| Packaging Dimension | 520mm×470mm×430mm |
| Net Weight | 12 kg |
| Gross Weight | 16 kg |
Pricing
| Product | Price | Unit | Action |
|---|---|---|---|
| Metallurgical Microscope LMMM-705 | $ 3075 | Each of 1 |
Features
Broad Field Eyepieces
Balanced Illumination System
Quintuple Revolving Nosepiece
Dual Focusing Knobs
Sturdy And Compact Build
Applications
Metallurgical Microscope LMMM-705 is ideal for analyzing microstructures and phase composition of various alloys in research and industry.
Similar Products
$ 2662.5 / Pack of 1
$ 5200 / Each of 1
$ 2550 / Each of 1
$ 2787.5 / Each of 1
$ 3700 / Each of 1
$ 4875 / Each of 1
$ 2425 / Pack of 1
Frequently Asked Questions
1 What is a Metallurgical Microscope?
A Metallurgical Microscope is an apparatus designed specifically for observing and analyzing the microstructure of metals and other solid materials.
2 How does Metallurgical Microscope work?
It works by using reflected light rather than transmitted light, allowing the observation of opaque specimens such as metals.
3 Can Metallurgical Microscope analyze grain size in metals?
It is commonly used to analyze grain size, phase boundaries, and microstructures in metallic samples.
4 What kind of samples can be observed under Metallurgical Microscope?
It can observe polished and etched metal samples, coatings, welds, failures, and surface treatments.
5 Can Metallurgical Microscope be used for quality control?
It is widely used in quality control processes to inspect metal parts for defects, uniformity, and adherence to industry standards.
6 Can Metallurgical Microscope be used for coating thickness measurement?
It is used to measure coating thickness by analyzing cross-sectional samples prepared through precise polishing and etching.
7 Can Metallurgical Microscope be used in studying corrosion?
It is used to study corrosion by examining surface pitting, intergranular attack, and oxide layer formation in metals.
8 How does Metallurgical Microscope assist in analyzing cast iron microstructures?
It assists in analyzing cast iron microstructures by revealing graphite morphology, matrix composition, and the distribution of carbides or pearlite.
9 How is Metallurgical Microscope used in the analysis of forged components?
It is used to inspect forged components for grain flow patterns, inclusions, and potential material segregation resulting from forging processes.
10 What is the role of Metallurgical Microscope in aerospace material testing?
It plays a key role in aerospace material testing by analyzing high-performance alloys for fatigue cracks, microstructural uniformity, and oxidation layers.
