Double Beam UV/Visible Spectrophotometer LMUD-A201 is designed with high-resolution touchscreen display that allow real time monintoring of measuring the absorbance or transmittance of light through a sample.With wavelength range between 190 to 1100 nm stimulate convenient spectrophotometric analysis. Improved with PC scanning software enabling data storage or analysis.
CatalogSpecifications
Wavelength | 190 nm – 1100 nm |
Spectral Bandwidth | 1 nm |
Optical System | Double Beam, grating (1200 lines/minute) |
Wavelength Accuracy | ± 0.3 nm |
Wavelength Repeatability | ≤ 0.1 nm |
Wavelength Setting | Automatic |
Photometric Range | 0 – 200 % T, - 3 ~ 3 A, 0 – 9999 C (0 – 9999 F) |
Photometric Setting | 0.2 % T (0 ~ 100 % T), ± 0 .002 A (0 ~ 0.5 A), ± 0.004 A (0.5 ~ 1 A) |
Photometric Repeatability | ≤ 0.15 % T (0 ~ 100 % T), 0.001 A (0 ~ 0.5 A), 0.002 A (0.5 ~ 1 A) |
Detector | Silicon Photodiode |
Light Source | Xenon Lamp |
Stray Light | ≤ 0.03 % (220 / 360 nm) |
Stability | ± 0.0005 A/h; 500 nm |
Data Output Port | USB / RS232 Port |
Noise | 0.0005 A; 500nm |
Baseline Flatness | ± 0.001 A |
Display | 7 |
Power Requirement | AC 220 / 110 V; 50 / 60 Hz |
Dimensions | 590 x 475 x 250 mm |
Net Weight | 20 Kg |
Gross Weight | 33 Kg |
Pricing
Product | Price | Unit | Action |
---|---|---|---|
Double Beam UV/Visible Spectrophotometer LMUD-A201 | $7,476.00 | Pack of 1 |
Features
High-quality flashing xenon lamp
7 inches Color LCD Display Screen
Supports USB & SD card storage
Automatic wavelength setting
High-quality electrical and optical system
PC scanning software
Low noise and low stray light
Optional Accessories
Model No | Specification | Image |
---|---|---|
A14 | Automatic 8-cell holder | |
A15 | Peltier/sipper system | |
A16 | Reflection accessories |
Applications
Double Beam UV/Visible Spectrophotometer is widely used in laboratories and pharmaceutical industry for analyzing drug formulations and determining the concentration of substances in solutions, such as proteins, nucleic acids, and other biomolecules.
