Double Beam UV/Visible Spectrophotometer LMUD-A102

Double Beam UV/Visible Spectrophotometer LMUD-A102

point.png Wavelength range: 190 nm – 1100 nm

point.png Spectral bandwidth: 1.8 nm

point.png Automatic wavelength setting

point.png Replaceable Pre-aligned lamps (Tungsten and Deuterium)

point.png High quality electrical and optical system

Get Quote
Wavelength 190 nm – 1100 nm
Spectral Bandwidth 1.8 nm
Optical System Double Beam, grating (1200 lines/minute)
Wavelength Accuracy ± 0.3 nm
Wavelength Repeatability ≤ 0.1 nm
Wavelength Setting Automatic
Photometric Range 0 – 200 % T, - 0.3 A ~ 3 A
Photometric Setting ± 0.3 % T (0 ~ 100 % T)
Photometric Repeatability 0.2 % T
Detector Silicon Photodiode
Light Source Tungsten Lamp and Deuterium Lamp
Stray Light 0.05 % T
Stability ± 0.0001 A/h; 500 nm
Data Output Port USB port & Parallel port ( Printer)
Noise 0.0001 A
Baseline Flatness ± 0.002 A
PC Software PC Scanning Software
Display Graphic LCD (128 x 64 Dots)
Power Requirement AC 220 / 110 V; 50 / 60 Hz
Dimensions 590 x 460 x 220 mm
Net Weight 16 Kg
Gross Weight 20 Kg

point.png Wavelength range: 190 nm – 1100 nm

point.png Spectral bandwidth: 1.8 nm

point.png Automatic wavelength setting

point.png Replaceable Pre-aligned lamps (Tungsten and Deuterium)

point.png High quality electrical and optical system

point.png USB port available

point.png Low noise and low stray light

point.png Optical PC scanning software (Optional)

Get Quote for
Double Beam UV/Visible Spectrophotometer LMUD-A102
