Heating Circulator LMHTC-A103 comes with working temperature of RT+5 to 250℃. It features PID control technology for stable, responsive temperature regulation and minimal fluctuation. Equipped with digital LCD interface for clear viewing and adjustment of operating parameters and status. Incorporates thermal overload, overcurrent, and phase sequence protection to safeguard operational components. Our Circulator ensures heat source for reactors, calorimeters, and pilot lines.
Specifications
| Working Temperature Range | RT+5 to 250℃ |
| Fluid Filling Volume | 17L |
| Flow Rate | 70L/min |
| Pressure | 1.5bar |
| Temperature Control Accuracy | ±0.5℃ |
| Outer Circulation Interface Size | R23/4 |
| Protection Grade | IP20 |
| Heating Power | 12kW |
| Power Consumption | 6.5kW |
| Power Supply | 380V,50Hz |
| Dimensions | 640×940×1585 mm |
| Net Weight | 185 Kg |
Pricing
| Product | Price | Unit | Action |
|---|---|---|---|
| Heating Circulator LMHTC-A103 | $ 6912.5 | Each of 1 |
Features
Sealed fluid circuit
Extended fluid lifespan
Liquid level monitoring
Leakage proof
Integrated cooling coil
Water inlet/outlet
Applications
Heating Circulator LMHTC-A103 is applied as heat source for reactors, calorimeters, fermentation tanks, pilot lines, and extraction units in pharmaceutical, chemical, and material industries.
