Muffle Furnace  LMMF-A303

Muffle Furnace LMMF-A303

LMMF-A303 range of molybdenum desilicide heated high temperature chamber furnace comprising different chamber sizes, available with maximum operating temperature of 1450°C. With the distinguished microprocessor program controller, it provides you with precise control of temperature range 500°C to 1400°C and easiness to operate this equipment. This unit is available in 22L capacity, having vacuum formed ceramic fibre insulation to prevent from over heat and short circuit.

Get Quote
Capacity 22 Liters
Maximum Temperature 1450°C
Operating Temperature Range 500°C - 1400°C
Temperature Control Microprocessor program control (2pattern 10 segment)
Thermocouple B-type
Insulation Ceramic board
Output Regulator SCR unit controller
Heating Element MoSi2 heater
Heater Capacity 9.6 Kw
Power AC220V, 50/60Hz, 1-phase
Internal Dimension (W×D×H) 250×350×250 mm
External Dimension (W×D×H) 920×710×850 mm

point.png Intelligent sensor alarm function

point.png Vacuum forced ceramic insulation

point.png Microprocessor program controller

point.png Auto-tuning function

point.png Intuitive and easy to use operating menu

point.png Current temperature and setting temperature is displayed separately on control panel

point.png Highly efficient fan motor ensures uniform air circulation

point.png Excellent temperature accuracy

point.png Simple to use and maintain

point.png Over-temperature limit function

point.png Less and low noise operation with gentle air currents

point.png Forced exhaust system

These furnaces are used for various purposes such as development of new materials, including industrial and biotechnology products are being used as the basis of a common laboratory equipment.
