Muffle Furnace LMMF-A205

Name: Muffle Furnace LMMF-A205
Brand: Labmate
SKU: LMMF-A205
Rating: 4.8 (485 reviews)

Muffle Furnace LMMF-A205 has known to be a dependable laboratory device. The well-known digital PID controller enables precise temperature control in the 1200°C range while also being simple to use. In the 27L capacity unit, ceramic fibre insulation prevents overheating and short circuiting. Because of its high performance-to-size ratio and quick heat-up rates, this compact muffle furnace is ideal for a wide range of applications.

Catalog

Specifications

Capacity	27 Liters
Maximum Temperature	1100°C up to 1200°C
Operating Temperature Range	300°C to 1000°C
Temperature Control	Digital PID controller, program type (5 pattern 18 segment)
Timer	99Hr 59min
Thermocouple	K-type
Insulation	Ceramic fiber
Internal Material	Ceramic fiber
External Material	Steel plate with powder coating
Heater Capacity	4 Kw
Power	AC 220V, 50/60Hz, 1-Phase
Internal Dimension (W×D×H)	300×300×300 mm
External Dimension (W×D×H)	580×590×780 mm
Weight	70 Kg

Pricing

Product	Price	Unit	Action
Muffle Furnace LMMF-A205	$4,150.00	Pack of 1

Features

Intelligent sensor alarm function
Digital PID controller
Auto-tuning function
Intuitive and easy to use operating menu
Easy to open door handles
Current temperature and setting temperature is displayed separately on control panel
Highly efficient fan motor ensures uniform air circulation
Excellent temperature accuracy
Simple to use and maintain
Over-temperature limit function
Less and low noise operation with gentle air currents
Forced exhaust system

Applications

These furnaces are used for various purposes such as development of new materials, including industrial and biotechnology products are being used as the basis of a common laboratory equipment.

Muffle Furnace LMMF-A102

Capacity: 5 Liters
Maximum Temperature: 850°C
Operating Temperature Range: 300°C to 800°C
Temperature Control: Digital PID controller
Timer: 99Hr 59min

Muffle Furnace LMMF-A501

Furnace Structure: Double layer with fan cooling
Insulation: High purity alumina fibre ceramic board
Max. Temperature: 1200 °C
Work Temperature: 1100 °C
Temperature control: 50 segments programmable and PID auto control

Muffle Furnace LMMF-A206

Capacity: 64 Liters
Maximum Temperature: 1100°C up to 1200°C
Operating Temperature Range: 300°C to 1000°C
Temperature Control: Digital PID controller, program type (5 pattern 18 segment)
Timer: 99Hr 59min

Muffle Furnace LMMF-A204

Capacity: 14 Liters
Maximum Temperature: 1100°C up to 1200°C
Operating Temperature Range: 300°C to 1000°C
Temperature Control: Digital PID controller, program type (5 pattern 18 segment)
Timer: 99Hr 59min

Muffle Furnace LMMF-A701

Capacity: 4.5 L
Temperature: 1200 °C
Working Temperature: 1100 °C
Thermocouple: N-type
Heating Rate: 25°C/min

Muffle Furnace LMMF-A203

Capacity: 12 Liters
Maximum Temperature: 1100°C up to 1200°C
Operating Temperature Range: 300°C to 1000°C
Temperature Control: Digital PID controller, program type (5 pattern 18 segment)
Timer: 99Hr 59min

Muffle Furnace LMMF-A302

Capacity: 11 Liters
Maximum Temperature: 1450°C
Operating Temperature Range: 500°C - 1400°C
Temperature Control: Microprocessor program control (2pattern 10 segment)
Thermocouple: B-type

Muffle Furnace LMMF-A402

Capacity: 11 Liters
Maximum Temperature: 1650°C
Operating Temperature Range: 500°C - 1600°C
Temperature Control: Microprocessor program control (2pattern 10 segment)
Thermocouple: B-type

Muffle Furnace LMMF-A403

Capacity: 22 Liters
Maximum Temperature: 1650°C
Operating Temperature Range: 500°C - 1600°C
Temperature Control: Microprocessor program control (2pattern 10 segment)
Thermocouple: B-type

Muffle Furnace LMMF-A101

Capacity: 3 Liters
Maximum Temperature: 850°C
Operating Temperature Range: 300°C to 800°C
Temperature Control: Digital PID controller
Timer: 99Hr 59min

Muffle Furnace LMMF-A503

Furnace structure: Double layer steel structure with fan cooling
Insulation: High purity alumina fibre ceramic board
Max. Temperature: 1700 °C
Work Temperature: 1600 °C
Temperature control: 50 segments programmable and PID auto control

Muffle Furnace LMMF-A201

Capacity: 3 Liters
Maximum Temperature: 1100°C up to 1200°C
Operating Temperature Range: 300°C to 1000°C
Temperature Control: Digital PID controller, program type (5 pattern 18 segment)
Timer: 99Hr 59min

Muffle Furnace LMMF-A504

Working Temperature: 1300℃
Highest Temperature: 1400℃
Capacity: 36L
Heating Rate: ≤20℃/Min
Temperature Control Accuracy: ±1℃

Muffle Furnace LMMF-A601

Capacity: 216 L
Maximum Temperature: 1700°C
Temperature Control: Digital PID controller
Thermocouple: B-type
Heater Capacity: 45 KW

Muffle Furnace LMMF-A502

Furnace structure: Double layer with fan cooling
Insulation: High purity alumina fibre ceramic board
Max. Temperature: 1400 °C
Work Temperature: 1300 °C
Temperature control: 50 segments programmable and PID auto control
