HPLC System LMHLS-A201 operates at temperatures ranging from 1°C to 45°C, ensuring consistent sample conditions. Provide a flow range of 0.001–10.000 mL/min for precise fluid control during separation. Offers high sensitivity and resolution for the accurate detection of analytes. Built-in Hg lamp calibration for precise and stable wavelength measurement. Our HPLC system is an essential tool for laboratories conducting complex chemical analyses.
Specifications
| Flow Rate Range | 0.001 to 10.000 ml/min |
| Maximum Operating Pressure | 45 MPa / 62 MPa |
| Maximum Injection Volume | 100 µl |
| Maximum Column Capacity | 300 mm column, 3 columns |
| Temperature Range | 1 to 45°C |
| Injector Capacity | 120 × 2 ml vials, 96-well plates compatible |
| Column Oven Temperature | 1 to 90°C |
| Column Switch | Optional |
| DAD Detector | 1024 diodes |
| Wavelength Calibration | Built-in Hg lamp for calibration |
| Maximum Sampling Rate | 160 Hz |
Pricing
| Product | Price | Unit | Action |
|---|---|---|---|
| HPLC System LMHLS-A201 | $ 51237.5 | Each of 1 |
Features
DAD Detector
High Sampling Rate
Large Injection Volume
Optional Column Switching
Easy to Operate
Applications
HPLC System LMHLS-A201 is essential for separating, identifying, and quantifying components in complex mixtures across industries and research fields.
Selection Guide
HPLC System LMHLS-A201 is a high-performance liquid chromatography unit designed for advanced research, analytical testing, and quality control across pharmaceutical, chemical, and biochemical laboratories. It features a wide flow rate range of 0.001 to 10.000 ml/min, making it suitable for both micro and standard-scale analyses. With a high maximum operating pressure of 45 MPa, extendable to 62 MPa, it supports high-resolution separations using longer or smaller particle-packed columns. The system allows a maximum injection volume of 100 µl, suitable for medium sample throughput, and can accommodate up to three 300 mm columns, providing flexibility for complex gradient elution and multi-component separations. Its robust design and capability to meet compliance standards and certifications make it reliable for regulated environments, ensuring accuracy, repeatability, and method adaptability in various scientific and industrial applications.
Similar Products
$ 49000 / Each of 1
$ 80741.25 / Each of 1
$ 60062.5 / Each of 1
$ 34982.5 / Each of 1
$ 36112.5 / Each of 1
$ 21000 / Each of 1
$ 51237.5 / Each of 1
$ 27437.5 / Each of 1
Frequently Asked Questions
1 What is a calibration curve in HPLC?
It is a graph that plots the known concentrations of a standard compound versus the detector response.
2 Is pH important in HPLC?
The pH of the mobile phase plays a crucial role in analyzing ionizable compounds.
3 Can HPLC be used for biomolecule analysis?
It is widely used for separation and analysis of biomolecules such as proteins, peptides and nucleic acids.
4 What is meant by elution strength in HPLC?
It refers to the ability of the mobile phase to elute the analytes from the stationary phase.
5 What is a HPLC?
A HPLC is an apparatus designed to separate, identify and quantify the components of a complex mixture.
6 On what principle is HPLC based on?
It is based on the differential interactions between the analytes and the stationary phase.
7 What is meant by resolution in HPLC?
Resolution refers to the ability of the system to separate two peaks.
8 What is meant by retention time in case of HPLC?
It is the time taken by specific compound to travel through the HPLC column and reach the detector.
