Soxhlet Extractor Fat Analyzer LMSFA-A401 performs fat content analysis in 5 extraction methods at temperatures of 5°C to 300°C. It is compatible with all organic solvents to meet diverse experimental demands. Equipped with pre-set reagent options and one click start/pause, it allows for streamlined and repeatable experiments. Integrated with leak detection system to protect operators and maintain sample integrity. Our Fat Analyzer is ideal for extracting soluble organic compounds from drugs, soil, sludge and cleaners.
Catalog Send Mail WhatsappSpecifications
Temperature range | Room temperature +5 ℃to 300 ℃ |
Measuring Range | 0.1 to 100% |
Temperature accuracy | ±1℃ |
Reproducibility | Relative error 1% |
Sample weight | 0.5 to 15 g |
Capacity per batch | 6 pcs/batch |
Display | 7 inches color touch screen |
Solvent cup volume | 150 mL |
Solvent recovery | ≥85% |
Controller | External via cable |
Power Supply | 220 VAC±10%, 50 Hz |
Power | 2.6 KW |
Dimensions (L×W×H) mm | 650×380×720 |
Net Weight | 50 Kg |
Features
Temperature and Flow Control
Heating Module
Glass and PTFE material
Magnetic Controller Mounting
Vertical Display Screen
Applications
Soxhlet Extractor Fat Analyzer LMSFA-A401 is ideal for extracting soluble organic compounds from drugs, soil, sludge, cleaners, and related substances and is widely employed in agriculture, food, chemicals, and environmental fields.
Similar Products
Frequently Asked Questions
1 What is a Fat Analyzer?
A Fat Analyzer is an apparatus designed for extracting soluble organic compounds from drugs, soil, food and beverage products.
2 Does Fat Analyzer test affect the texture of food?
It provides simple, non-destructive testing of food without altering its physical properties.
3 Does Fat Analyzer require solvent for analysis?
It provides reliable results without needing any solvent.
4 What kind of beverages can be tested using Fat Analyzer?
It is used to test beverages that contain fat content such as milk and cream.
