Plate Load Test Apparatus LMPLT-A100 delivers reliable load testing with straight-through load plate of 300 mm. Incorporated with strong frame for reliable testing even under heavy pressure. Equipped to calculate deformation modulus of uniform foundation soil under various load conditions. It features an advanced hydraulic system for consistent load application and measurement. Our Apparatus is designed for evaluating soil strength and foundation performance in construction works.
Catalog Send Mail WhatsappSpecifications
| Load Plate Diameter | 300 mm |
| Jack Stroke | 120 mm |
| Span of Side Bridge | 3000 mm |
| Operating Temperature Range | 5°C to 45°C |
| Pressure Range | 25 MPa |
| Displacement Range | 0 to 10 mm |
| Hydraulic Oil Type | Lubricating, wear-resistant |
Features
Advanced hydraulic system
Dial indicator for measurements
Height-adjustable beam design
Strong, durable construction
Applications
Plate Load Test Apparatus LMPLT-A100 is employed for testing soil foundation bearing capacity. It evaluates fine-grained soils, compacted subgrades, and base layers for deformation modulus.
Frequently Asked Questions
1 What is a Plate Load Test Apparatus?
A Plate Load Test Apparatus is an equipment designed for evaluating safe bearing capacity and settlement characteristics of foundation soil.
2 What types of soil can be tested using Plate Load Test Apparatus?
It is suitable for testing sandy, clayey and mixed soils.
3 What is ultimate bearing capacity of Plate Load Test Apparatus?
The ultimate bearing capacity is the maximum load that can be applied to the plate before excessive settlement or failure of the soil.
4 Can Plate Load Test Apparatus be used for foundation redesign?
It is commonly used for evaluating the existing soil conditions beneath an existing foundation.
5 Can Plate Load Test Apparatus be used for both cohesive and granular soils?
It can be used for both cohesive soils and granular soils.
6 How does Plate Load Test Apparatus help in the design of retaining walls?
It provides valuable insights on the bearing capacity and settlement behavior of the soil behind retaining walls.
7 Can Plate Load Test Apparatus be used in geotechnical investigations for road construction?
It is used to evaluate the bearing capacity of the soil along the roadbed and predict the settlement behavior under vehicular loads.
8 On what factors does the maximum load of Plate Load Test Apparatus depends upon?
The maximum load that can be applied in Plate Load Test Apparatus depends on the capacity of the loading equipment, the size of the plate and the bearing capacity of soil.
9 Can Plate Load Test Apparatus be used for both saturated and unsaturated soils?
It can be used for both saturated and unsaturated soils.
10 Can Plate Load Test Apparatus be used on sloped or uneven terrain?
It can be used on sloped or uneven terrain.
