LUX Meter LMLXM-A100 measures illumination from 0 to 1000000 Lux. It evaluates illuminance UV index, flicker CRI, CCT and temperature across lighting scenarios. Equipped with spectral sensor for consistent lighting assessment in indoor and outdoor settings. Integrated with spectral curve display to identify lighting types and assess blue light hazards. Our Meter is ideal for lamps, outdoor lighting, greenhouses, and stage lighting analysis
Specifications
| Measurement Range | 0 to 1000000 Lux |
| Resolution | 0.1 Lux |
| Accuracy | Less than or equal to ±(3%H + 2 Lux) |
| Illuminance Wavelength Range | 400nm to 700nm |
| Illuminance Wavelength Interval | 10nm |
| CCT Measurement Range | 1000 to 100000K |
| CCT Accuracy | ±5% |
| CRI Measurement Range | 0 to 100 |
| CRI Accuracy | ±2 |
| UV Index Range | 0.0 to 15.0 |
| UV Index Accuracy | ±0.5 |
| Flicker Frequency Range | 10 to 500 Hz |
| Flicker Frequency Accuracy | ±5% |
| Temperature Range | -20℃ to 80℃ |
| Temperature Accuracy | ±0.5℃ |
| Humidity Range | 0% to 90% RH |
| Humidity Accuracy | ±4%RH |
| PPFD Range | 0 to 10000 μmol/m²/s |
| PPFD Accuracy | Less than or equal to ±(5%H + 0.5 μmol/m²/s) |
| PPFD (Blue, Green, And Red) Range | 0 to 5000 μmol/m²/s |
| PPFD (Blue, Green, And Red) Accuracy | Less than or equal to ≤±(10%H + 0.5 μmol/m²/s |
| YPFD Range | 0 to 10000 μmol/m²/s |
| YPFD Accuracy | Less than or equal to ±(5%H + 0.5 μmol/m²/s) |
| Chlorophyll Range | 0 to 10000 μW/cm² |
| Chlorophyll Accuracy | Less than or equal to ±(10%H + 0.5 μW/cm²) |
| Response Time | Less than 0.7 seconds |
| Operating Temperature | 0 to 40℃ |
| Operating Humidity | Less than 85% RH |
| Test Aperture Diameter | Φ21mm |
| Battery | 2 AA Alkaline Batteries |
| Power Consumption | 60mW |
| Power Supply | DC 3V |
| Dimensions | 187.1mm × 72mm × 28mm |
| Weight | About 199g (including battery) |
Pricing
| Product | Price | Unit | Action |
|---|---|---|---|
| LUX Meter LMLXM-A100 | $ 1075 | Each of 1 |
Features
Compact handheld design
Durable ABS body
Low battery alert
Standard Accessories
Model No. | Accessories |
LMLXM-A100-S1 | Spectral Illuminance Meter |
LMLXM-A100-W1 | Warranty card |
LMLXM-A100-R1 | Calibration Report |
LMLXM-A100-C1 | Carrying case |
Applications
LUX Meter LMLXM-A100 is suitable for home gardening plant factories greenhouses plant lighting and agricultural research.
Selection Guide
When selecting the LUX Meter LMLXM-A100, customers should consider its advanced specifications and suitability for various research and industrial applications. Based on studies and practical use, this meter is suitable for environments requiring high-accuracy light measurements, such as laboratories, cleanrooms, agricultural research, LED testing, museum lighting evaluations, and environmental monitoring. It provides a wide measurement range of 0 to 1,000,000 Lux with a fine resolution of 0.1 Lux, making it suitable for both low-light and high-intensity conditions. The accuracy of ≤ ± (3%H + 2 Lux) ensures reliable data for experiments and compliance purposes. With a wavelength sensitivity from 400nm to 700nm, it effectively covers the visible light spectrum, which is critical for evaluating human-centric lighting and photobiological studies. Additionally, the device is often used in certified testing laboratories and complies with international quality and safety standards, ensuring credibility in regulatory and quality assurance processes.
Similar Products
$ 5625 / Box of 1
Frequently Asked Questions
1 What is a LUX Meter?
A LUX Meter is an apparatus designed to measure the intensity of light in a given area.
2 How does LUX Meter work?
It works by using a photodiode sensor that converts light into an electrical signal, allowing the LUX Meter to calculate and display light intensity.
3 How does LUX Meter assist in greenhouse farming?
It assists in greenhouse farming by monitoring the amount of light plants receive, allowing growers to use the LUX Meter to optimize lighting for healthy plant growth and energy efficiency.
4 How does LUX Meter support energy-efficient lighting upgrades?
It supports energy-efficient lighting upgrades by providing accurate light readings before and after installations.
5 How does LUX Meter help in airport or runway lighting inspections?
It helps in airport or runway lighting inspections by ensuring critical areas are properly illuminated for safety.
6 Can LUX Meter assist in designing energy-saving lighting systems?
It assists in designing energy-saving lighting systems by identifying over-lit or under-lit zones.
7 Is LUX Meter applicable in underground mines?
It is applicable in underground mines to measure and monitor artificial lighting.
8 How does LUX Meter help monitor light pollution in urban areas?
It helps monitor light pollution in urban areas by measuring ambient light at night.
9 Why is LUX Meter important in surgical or medical lighting environments?
It is important in surgical or medical lighting environments because it ensures that lights meet strict brightness requirements.
10 What role does LUX Meter play in construction site lighting compliance?
It plays a role in construction site lighting compliance by measuring illumination to meet safety and regulatory standards, where the LUX Meter ensures proper visibility in all work zones.
