Universal testing machine LMUTM-A100 Catalog

Overview

Universal testing machine LMUTM-A100 is a versatile mechanical testing device used to evaluate various material properties. It tests different samples laminated materials, wood, leather, rubber & plastic, metal material, etc. Safeguard mechanism to prevent malfunctions and ensures precision in obtaining results. The results help in quality control, research, and the design of materials and products.

Features :

Precise materials testing capabilities
Conducts various tests using distinct grips
Tests deformation under defined load of tested sample
Software generates word/excel report with results of measured properties
High resistance to interference improves both reliability and accuracy
Safety alert for overload, overcurrent, overpressure, and displacement limits
High-precision mechanical ball screw rod provides precise and reliable motion
AC servo system and servo motor boosts stability and reliability of the device

Specifications :

Maximum force	100 KN (10 T)
Load accuracy	0.5 % F.S
Force reading units	kgf, lbf, N, K N, T
Motor	AC Servo motor with variable speed drive system, high-precision mechanical ball screw rod
Stretching stroke	600 mm
Compression space	600 mm
Test width	450 mm
Testing speed	0.01 to 500 mm/min (adjustable)
Control system	PC with windows 7 system
Software	TM2101
Data display	Max. force, speed, sample information, strength (Kpa, Mpa, N/mm, N/mm2) etc.
Curves display	Load- elongation, Elongation-time, Time-elongation, Stress-strain
Safety features	E-Stop, Over-load protection, Upper and lower limit switches, Load sensor with automatic retreat

Applications :

Universal testing machine is widely used for testing the tensile strength, compression, bend, peel, tear, shear, friction, puncture and other mechanical tests across quality analysis firms, research, metallurgy, construction sector and automobiles.
